Audience je tri-band (1 x 2,4GHz i 2 x 5GHz ) access point sa meshing tehnologijom, koji omogućava maksimalnu pokrivenost objekata koji nemaju kablovsku infrastrukturu i vrhunsko pokrivanje svakog dijela istog objekta. U zavisnosti od veličine objekta/prostorije, vrlo je jednostavno dodavati potreban broj ovih uređaja i na taj način proširiti pokrivenost WiFi mrežom, a sve to uz jednostavnu konfiguraciju preko iOS ili Android aplikacije.
Uređaj dolazi sa dva gigabitna porta (jedan ima Passive PoE in podršku), quad-core procesorom i 256 MB RAM memorije.
Dostupna je i verzija sa LTE podrškom koja je praktična tamo gdje je potrebno imati backup konekciju.
Na osnovu svega možemo zaključiti da Audience predstavlja budućnost laganog i elegantnog umrežavanja!
Detaljne specifikacije uređaja
Specifications
| Details |
| Product code |
RBD25G-5HPacQD2HPnD |
| Architecture |
ARM 32bit |
| CPU |
IPQ-4019 |
| CPU core count |
4 |
| CPU nominal frequency |
716 MHz |
| Switch chip model |
IPQ-4019 |
| Dimensions |
100 x 235 x 97 mm |
| RouterOS license |
4 |
| Operating System |
RouterOS |
| Size of RAM |
256 MB |
| Storage size |
128 MB |
| Storage type |
NAND |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-40°C to 60°C |
| IPsec hardware acceleration |
Yes |
Wireless capabilities
| Details |
| Wireless 2.4 GHz Max data rate |
300 Mbit/s |
| Wireless 2.4 GHz number of chains |
2 |
| Wireless 2.4 GHz standards |
802.11b/g/n |
| Antenna gain dBi for 2.4 GHz |
3.5 |
| Wireless 2.4 GHz chip model |
IPQ-4019 |
| Wireless 2.4 GHz generation |
Wi-Fi 4 |
| |
|
| Wireless 5 GHz Max data rate |
867 Mbit/s |
| Wireless 5 GHz number of chains |
2 |
| Wireless 5 GHz standards |
802.11a/n/ac |
| Antenna gain dBi for 5 GHz |
4.5 |
| Wireless 5 GHz chip model |
IPQ-4019 |
| Wireless 5 GHz generation |
Wi-Fi 5 |
| |
|
| Wireless 5 GHz Max data rate |
1733 Mbit/s |
| Wireless 5 GHz number of chains |
4 |
| Wireless 5 GHz standards |
802.11a/n/ac |
| Antenna gain dBi for 5 GHz |
4.5 |
| Wireless 5 GHz chip model |
QCA9984 |
| Wireless 5 GHz generation |
Wi-Fi 5 |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
2 |
Powering
| Details |
| Number of DC inputs |
2 (DC jack, PoE-IN) |
| DC jack input Voltage |
12-57 V |
| Max power consumption |
27 W |
| Max power consumption without attachments |
27 W |
| Cooling type |
Passive |
| PoE in |
Passive PoE |
| PoE in input Voltage |
24-57 V |
Certification & Approvals
| Details |
| Certification |
CE, FCC, IC, EAC, ROHS |
| IP |
IP20 |
Wireless specifications
| 2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 1MBit/s |
26 |
-100 |
| 11MBit/s |
26 |
-94 |
| 6MBit/s |
29 |
-96 |
| 54MBit/s |
26 |
-80 |
| MCS0 |
29 |
-96 |
| MCS7 |
25 |
-75 |
| 5 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 6MBit/s |
28 |
-95 |
| 54MBit/s |
25 |
-78 |
| MCS0 |
28 |
-95 |
| MCS7 |
24 |
-75 |
| MCS9 |
22 |
-70 |
| 5 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 6MBit/s |
32 |
-96 |
| 54MBit/s |
28 |
-80 |
| MCS0 |
32 |
-96 |
| MCS7 |
27 |
-77 |
| MCS9 |
25 |
-72 |
