MikroTik LtAP mini je wireless access point sa integrisanim LTE antenama i miniPCI-e slotom koji je otporan na vremenske uslove.
LtAP mini takođe ima jedan 10/100 Ethernet LAN port. RS232 serijski port daje konzoli pristup za otklanjanje grešaka i ima nekoliko opcija za napajanje: 12-57V PoE-in od strane ethernet porta, 8-30V DC džek i 5V microUSB.
Detaljnje specifikacije uređaja
Specifications
| Details |
| Product code |
RB912R-2nD-LTm |
| Architecture |
MIPSBE |
| CPU |
QCA9531 |
| CPU core count |
1 |
| CPU nominal frequency |
650 MHz |
| Dimensions |
139 x 77 x 28,5 mm |
| RouterOS license |
4 |
| Operating System |
RouterOS |
| Size of RAM |
64 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 100'000 hours at 25C |
| Tested ambient temperature |
-40°C to 70°C |
Powering
| Details |
| MicroUSB input Voltage |
5 V |
| Number of DC inputs |
3 (PoE-IN, DC jack, MicroUSB) |
| DC jack input Voltage |
8-30 V |
| Max power consumption |
9 W |
| Max power consumption without attachments |
4 W |
| Cooling type |
Passive |
| PoE in |
802.3af/at |
| PoE in input Voltage |
12-57 V |
Wireless specifications
| Details |
| Wireless 2.4 GHz Max data rate |
300 Mbit/s |
| Wireless 2.4 GHz number of chains |
2 |
| Wireless 2.4 GHz standards |
802.11b/g/n |
| Antenna gain dBi for 2.4 GHz |
1.5 |
| Wireless 2.4 GHz chip model |
QCA9531 |
| Wireless 2.4 GHz generation |
Wi-Fi 4 |
Ethernet
| Details |
| 10/100 Ethernet ports |
1 |
Peripherals
| Details |
| Number of SIM slots |
2 Modem (Mini SIM) |
| MiniPCI-e slots |
1 |
| Serial console port |
RS232 |
Other
| Details |
| Mode button |
Yes |
| GNSS standards |
GPS |
| GPS RF connector type |
uUFL |
Certification & Approvals
| Details |
| Certification |
CE, FCC, IC, E-MARK, EAC, ROHS |
| IP |
IP54 |
Wireless specifications
| 2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 1MBit/s |
22 |
-96 |
| 11MBit/s |
22 |
-89 |
| 6MBit/s |
20 |
-93 |
| 54MBit/s |
18 |
-74 |
| MCS0 |
20 |
-93 |
| MCS7 |
16 |
-71 |
