Ubiquiti UACC-LRE je gigabitni Ethernet repeater dizajniran za proširenje PoE (Power over Ethernet) veza na duže udaljenosti – do 1 km, uz minimalan gubitak signala. Idealno je rješenje za povezivanje uređaja poput pristupnih tačaka (AP) ili kamera koje su udaljene od glavnog PoE+ switch-a.
Overview
Dimensions
196.5 x 93.5 x 39 mm (7.7 x 3.7 x 1.5")
Weight
350 g (12.3 oz)
Enclosure Material
UV stabilized polycarbonate
Mounting Material
Stainless steel
Weatherproofing
IPX5
Ambient Operating Temperature
-40 to 80° C (-40 to 176° F)
Ambient Operating Humidity
10 to 95% noncondensing
NDAA Compliant
✓
Certifications
CE, FCC, IC
Power Method
PoE/PoE+ 2-pairs (Pins 1, 2+; 3, 6-)
Max. Power Consumption
1.5W (Excluding PoE output)
Networking Interface
(2) GbE RJ45 ports
PoE Interface
(1) Passthrough PoE output 2-pairs (pins 1,2+; 3,6-)
Total Non-Blocking Line Rate
2 Gbps
Switching Capacity
4 Gbps
Forwarding Rate
1.488 Mpps
Total Available PoE
22.5W
Voltage Range PoE Mode
37—57V DC
ESD/EMP Protection
Air/contact: ± 30kV
DC Sparkover Voltage
90V at 100V/s
Max. Impulse Sparkover Voltage
700V at 1kV/μs
Discharge Current
10kA+
Max. MTU
1,500 bytes
LEDs
Blue: power ON
Green: 1 Gbps Amber: 10/100 Mbps
Amber: passthrough PoE outOverview
